Injectable Liquid Filling Machine – Vial
Laxmi Pharma Equipment is one of the leading manufacturers and exporter and Supplier of Injectable Liquid Filling Machine – For Vials.
Compact automated volumetric multi head vial liquid filling and rubber stoppering machines are available from Laxmi Pharma Equipment. The apparatus consists of silicon rubber tubings, easy-to-reach compact panels, precision-built S.S. -316 syringes, turntables, a S.S. slat conveyor belt, and eccentric pre-gassing, filling, and post-gassing nozzles. Its smallest gap between the stopper and filler reduces the possibility of contamination.
Working Principle
It is designed for operating in a sterile area and for utilizing it under laminar flow protection. The un-scrambler itself has been designed in the machine to eliminate dead ends and difficult-to-clean spots.
The two types of liquid vial filling machines—one with ordinary pressure and the other with a vacuum—are categorized according to how they function. Gravity is the primary operating principle of a normal pressure device, whereas a vacuum-filling device operates on the weight of the liquid that is filled into the bottle. we’ve explored the working principles of injectable liquid filling machines for vials, highlighting their significance in pharmaceutical and healthcare applications. These machines are at the forefront of dosage accuracy and sterility in medication packaging.
APPLICATIONS
PHARMACEUTICAL
FOOD & BEVERAGES
COSMETIC
PESTICIDES
CHEMICAL
SALIENT FEATURES
- All Liquid Contact Parts are of S.S. 316, the Body Structure is built up of S.S. 304 Pipe.
- Co-eccentric Nozzles allows very quick and precise setting and making unit compact and manageable.
- Crafted S.S. Holder, Lapped Glass as well as S.S. Syringes and piston and precision built Valve System for achieving very high accuracy in fill size and drip proof performance. Precise setting and accuracy can be easily adjusted on the machine itself.
- No vial No Stopper – No Filling System.
- Easy reach compact panel provided easy and operation.
- Minimum Change over Time. From one size of container or fill size to another.
- Can run dry and wet rubber stoppers and supplied with liquid collection tray..
TECHNICAL SPECIFICATION
| Model | LVFS-60 | LVFS-100 | LVFS-150 | LVFS-200 |
|---|---|---|---|---|
| Filling Type | Dive-in | Dive-in | Dive-in | Dive-in |
| Grade | Automatic | Automatic | Automatic | Automatic |
| Suitability | Water base liquids | Water base liquids | Water base liquids | Water base liquids |
| Vial Diameter Range | Up to 50mm | Up to 50mm | Up to 50mm | Up to 50mm |
| Input/output Type | Manuel on Turn table | Manuel on Turn table | Manuel on Turn table | Manuel on Turn table |
| Pumps Nos | 2 | 4 | 6 | 8 |
| Filling Accuracy | ±1 % | ±1 % | ±1 % | ±1 % |
| Output/Min | 50-60 Vials | 80-110 Vials | 130-150 Vials | 180-200 Vials |
| Rubber Stopper | 13/20 mm | 13/20 mm | 13/20 mm | 13/20 mm |
| Dimensions (L X W X H) | 1400 X 850 X 1350 | 1500 X 850 X 1400 | 1530 X 850 X 1400 | 2000 X 850 X 1450 |
