Automatic Multi Head Ampoules Filling– Sealing Machine
Laxmi Pharma Equipment is one of the leading manufacturers and exporter and Supplier of Automatic Multi Head Ampoules Filling–Sealing Machine.
The “LAFS” Series Compact Automatic High Speed Multi Head Ampoule Filling & Sealing Machine is available from Laxmi Pharma Equipment. The machine is composed of a square pipe frame constructed of S.S. and fully finished with S.S. coverings. Additionally, there is a big hole on the bottom side for effortless and thorough cleaning. To ensure ease of use and safety, the electrical control panel of the pendant type is elevated from the machine.
Working Principle
They are built on the principle of slant traveling of ampoules when it is filled and sealed while the equipment takes care of customized factors like the neck dimension of the container, its thickness, and form.
Automatic multi-head ampoule filling–sealing machines are specialized equipment used for precise filling and sealing of ampoules, which are small sealed vials containing a sterile solution or medication. These machines are essential in pharmaceutical, biotech, and healthcare settings where dosage accuracy and sterility are paramount. The process begins with an ampoule feeding system, which loads empty ampoules onto a conveyor or a rotary platform, preparing them for filling and sealing.
APPLICATIONS
PHARMACEUTICAL
FOOD & BEVERAGES
COSMETIC
PESTICIDES
CHEMICAL
SALIENT FEATURES
- Self-centering grippers for the transport of all ampoule diameters within the size range without the need to change.
- Ampoule gas centering during gas flushing and filling.
- Possibility of gas flushing before, during and after filling.
- Drip free adjustment for media of different viscosity.
- No ampoule No filling & Sealing system.
- Full accessibility allows easy maintenance.
- Fast change over due to extremely limited parts to be replaced.
- Individual micro metric adjustment of syringes.
- Ampoule sampling unit without stopping the machine.
- Higher output up to 15000 Ampoules per hour.
- Flow Meters Makes Regulating Flames easier.
TECHNICAL SPECIFICATION
| Model | LAFS-30 | LAFS-55 | LAFS-100 | LAFS-150 |
|---|---|---|---|---|
| No. of Syringes | One | Two | Four | Six |
| Optimum Output Per Minute | 20 to 30 | 40 to 55 | 80 to 100 | 100 to 150 |
| Ampoule Size/ Range | 1 to 20 ML | 1 to 10 ML | 1 to 5 ML | 1 to 5 ML |
| Power required over all | 0.5 H.P. | 0.75 H.P. | 1 H.P. | 1.5 H.P. |
| Dimension | 915 mm (L) | 915 mm (L) | 1200mm (L) | 2000 mm(L) |
| 610 mm (W) | 760 mm (W) | 1070mm (W) | 1400 mm(W) | |
| 965 mm (H) | 965 mm (H) | 965 mm(H) | 1500 mm(H) |
